Medical valve V180

medical gasmanual

V180 is a gate valve with body, bonnet and most of the internal parts made of aluminum. The valve brings a higher level of safety in gas piping systems. It can be activated by a manual handwheel or pneumatic actuator. V180 valve is designed for combustive gases, pure gases and oxidizing gases. Key advantages Can be used with both direction Leakage class IV-1 Pressure up to 50b Minimum pressure losses under medim pressure Oil free standard Specifications Operating press. range (ps) 0 to 50 bar Operating temp. range (ts) - -20 to +60 °c Direction of flow - Both direction Installation Vertical - actuator up Lackage class Taux A (acc. to EN 12266-1) or IV-1 (acc. to DIN3230 STD) Seat diameter 050 to 0300 Mm Material (envelope) Copper-Aluminium (CuAl) Material (o-ring) FPM Material (seat/guiding) PCTFE Electrical conductivity - Copper braid between shutter and body Production tests - Individual tests (hydraulic at 75 bars leaktightness at 55 bars) Manual actuation Handwheel Electrical actuation Servodrive Pneumatic actuation Double acting actuation (auto-pneumatique) Dimensions DN50 to DN300 (ISO PN50 STD flanges) Face and finish RF (Raised Face), FF (Flat Face), Ring Type Joint (RTJ) Other on demand
