In all position, optional: plastic or metal bracket with fixing holes
Applications
Hydromassage tubs
Multi-function hydromassge showers
Water and sanitary installations
Floorwashing machiines
High-pressure water jet machines
Metering devices
Water dispensers
Ice Machines
Steam boilers
Irrigation systems for verandas and gardens
Physical characteristic
Valve body PA 66 - 30% GF
Core pin NBR
Coils F Class (155°)
Assembly Bayonet
ELectrical Connections
Faston 6,3 x 0.8 mm
Unipolar wires max 5000 mm
Bipolar wires max 5000 mm
