- - Console TFT 10.1” touch screen;
- - Pc Arm A7 Dual core OS Linux Debian 7.0;
- - USB;
- - WiFi;
- - RS232 output (Trackmaster protocol);
- - Speed Max 20 km/h;
- - Speed Min 0.1 km/h;
- - Speed Increment 0.1 km/h;
- - Inclination Max 22%;
- - Inclination Min 0%;
- - Inclination increment 0.5 / 1%;
- - Electronic variation of speed and inclination;
- - Cardio recording: hand grip + chest belt;
- - Self-centring belt system;
- - Self-lubrication belt system;
- - Walking surface: 140 x 48 cm;
- - Transformer 1700 VA;
- - Inverter 1.5 kw;
- - Power supply 220~240Vac 50/60 Hz 10Amp;
- - Auxiliary circuit of inclination: 18 Vac;
- - Auxiliary circuit of console: 12 Vcc;
- - Motor power (max peak) 5 HP (AC);
- - Absorbed power at max speed 2000 VA;
- - Nominal absorbed power 1500 VA;
- - Noise < 30 DB;
- - Damped board;
- - User’s max weight 150 kgs;
- - Emergency stop button and pull rope with magnet;
- - Certificate of conformity to EEC93/42 Rule (medical device);
Standard accessories:
- - Wheels for movement;
- - Chest belt;
- - Service equipment;
Optional accessories:
- - Long size handrails;
- - Under arm kit;
- - Adjustable and removable seat;
- - Harness system;
- - Ramp;
- - Software RunnerConnect;
- - Inclination -3% / +19%;
Console functions :
- - Manual use
