Width: 80 cm
Lenght: 210 cm
Height: 150 cm
Weight: 180 kgs
Technical specifications:
- 10.1” touch screen monitor resistive;
- PC iMX6 DL 1GB, Micro SD 8GB, OS Linux;
- USB output;
- RS232 output (Trackmaster protocol);
- Speed Max 25 km/h;
- Speed Min 0.1 km/h;
- Speed Increment 0.1 km/h;
- Inclination Max 30% or 28%
- Inclination Min 0% or -2%
- Inclination increment 0.5 / 1%;
- Electronic variation of speed and inclination;
- Cardio recording: chest belt;
- Self-centring belt system;
- Self-lubrication belt system;
- Walking surface: 154.5 x 54 cm;
- Transformer 1700 VA;
- Inverter 2.2 kw;
- Power supply 220~240Vac 50/60 Hz 12Amp;
Auxiliary circuit of inclination: 18 Vac;
Auxiliary circuit of console: 12 Vdc;
Motor power (max peak) 7 HP (AC);
Absorbed power at max speed 2500 VA;
Nominal absorbed power 2000 VA;
Noise < 30 DB;
Damped board;
User's max weight 220 kgs;
Emergency stop button and pull rope with magnet; Certificate of conformity to EEC93/42 Rule (medical device);
Standard accessories:
Wheels for movement;
Chest belt;
Service equipment;
Optional accessories:
Long size handrails;
Under arm kit;
Adjustable and removable seat;
Harness System;
Ramp;
Software RunnerConnect;
Console functions (picture 1):
Manual use (picture 2);
