Width: 80 cm
Lenght: 210 cm
Height: 150 cm
Weight: 180 kgs
Technical specifications:
- 10.1” touch screen monitor resistive;
- PC iMX6 DL 1GB, Micro SD 8GB, OS Linux;
- USB output;
- Wifi
- TV(web) / Radio;
- RS232 output (Trackmaster protocol);
- Speed Max 25 km/h;
- Speed Min 0.1 km/h;
- Speed Increment 0.1 km/h;
- Inclination Max 30%;
- Inclination Min 0%;
- Inclination increment 0.5 / 1%;
- Electronic variation of speed and inclination;
- Cardio recording: hand grip + chest belt;
- Self-centring belt system;
- Self-lubrication belt system;
- Walking surface: 154.5 x 54 cm;
- Transformer 123 VA;
- Inverter 2.2 kw;
- Power supply 220~240Vac 50/60 Hz 12Amp;
- Auxiliary circuit of inclination: 18 Vac;
- Auxiliary circuit of console: 12 Vdc;
- Motor power (max peak) 7 HP (AC);
- Absorbed power at max speed 2500 VA;
- Nominal absorbed power 2000 VA;
- Noise < 30 DB;
- Damped board;
- User’s max weight 220 kgs;
- Emergency stop button;
- Certificate of conformity to EC Rules;
Standard accessories:
- Wheels for movement;
- Chest belt;
- Bottle holder;
- Service equipment.
Console functions (picture 1):
- Manual use (picture 2);
- Cardio (picture 3);
- Fat burning (picture 3);
- Time (picture 4);
- Distance (picture 5);
- Calories (picture 6);
- 10 Profiles (pre-set) (picture 7/8);
- 100 Free profiles (picture 7/8);
- Test: CHR test, CWL test, COOPER test,
VAMEVAL test, RUNNER test, BRUCE test,
BRUCE MODIFIED test, ASTRAND MODIFIED test,
ELLESTAD test, ACIP test, TEST01-08 (picture 9);
- Exercise saving on USB key (picture 10).
