Absorbance test probe FLEX Pack

flowoperational

Use Transmittance Probes to Measure Absorbance Monitoring the Absorbance Inside Containers and Reactors Fully Configurable Spectrometer (Including Interchangeable Slits) Transmittance Probes with different pathlengths available: 2, 5 and 10 mm Fast Sample Screening as low as 2ms Integration Time The Absorption FLEX Pack Probe is a flexible bundle with all the necessary optical components to perform absorbance and transmittance measurements of solutions that are unable to be placed into a cuvette or a flow cell. This bundle can be configured for three operational wavelength ranges: UV-Vis, Vis-NIR, and UV-Vis-NIR. All of these configurations provide an optical resolution better than 1.6 nm (FWHM) within the operational range selected and a fast sample screening with a minimum integration time of 2 ms. To attain maximum light efficiency, both narrow-range UV-Vis and extended-range UV-Vis-NIR configurations include a high-stability and high-power UV-Vis-NIR deuterium and tungsten-halogen light source (LS-DWHP) while the narrow-range Vis-NIR configuration includes a high-power tungsten-halogen light source (LS-W20). The spectrometer included in this bundle is the FLEX STD, which can be user-configured for the wavelength range with blazed holographic gratings that have a strong stray light rejection. This Absorption FLEX Pack Probe bundle is completed with a user-configured transmittance immersion probe.
