Medical autoclave P series

surgicalethylene oxidefloor-standing

The P Series autoclaves are pressurised chambers used for sterilisation using an ethylene oxide mixture. They are constructed in AISI 304 steel and are equipped with an airtight sliding door. The closure system has been designed to be easy to manoeuvre, and, for special goods handling requirements, a second door can be fitted that can open right or left in line with the chamber’s orientation. The advantage of pressurised autoclaves is that they favour a greater speed of penetration of the sterilising gas into the packaging, thus enabling a greater number of sterilisation cycles to be performed. Technical details Hermetically sealed sliding door; Possibility of adding a second door; Internal pallet handling system; CE and PED certification; Electrical panels; Supervision and control software (PLC and SCADA); Insulation layer; Parallelepiped shape. Applicable standards The equipment complies with European standards UNI EN ISO 11135:2014 – Ethylene oxide: Requirements for the development, validation and routine control of a sterilisation process for medical devices; 2014/35/EC (Low Voltage); 2014/30/EC (EMC); 2006/42/EC (MD); and 2014/68/UE (PED).
