The OSM-100 surgical operating microscope has a high resolution, definition, and strong stereo perception. It adopts a high-eye-point wide-angle eyepiece with a flat field of view. The excellent optical system and reliable operating structure make the imaging clearer and the operation simpler. The system separates the left and right optical paths, and the deflecting prisms make the object form a positive image, which aligns with human physiological habits. Technical Parameters Magnification factor: 7X-45X or3.5X-180X (optional additional objective+eyepiece combination) Continuous doubling ratio: 1:6.5 Observation lens tube: hinged trinocular, tilted at 45 degrees, pupil spacing: 55mm-75mm Eyepiece: high eye point and large field of view, wide-angle WF10X/diameter 20mm Objective: Continuous zoom objective, 0.7X-4.5X, ensuring image plane is parfocal Diopter: binocular vision adjustment range ± 6 Field of view diameter: 5mm -30mm Working distance: 30mm-160mm Base size: 210mm x 260mm Column height: 368mm Horizontal dimension: 510mm Applications Suitable for animal surgical anatomy, teaching, etc.
