Fingertip SpO2 sensor AMD-RS-PC6502-S

pediatrictransflectancereflectance

Compatible Nellcor OxiMax 1 Meter 9Pin Pediatric Finger Clip Reusable SpO2 Sensor Compatible Model: N-10, N-180, N-190, N-20, N-30, N-560, N-600, N-600x, N-65, N-85, NPB-190, NPB-195, NPB-3910, NPB-3920, NPB-3930, NPB-3940, NPB-40, NPB-4000, NPB-75, PM10N, Sensors that have Nellcor OxiMax Technology and 9 pins. Cable Color:Gray Cable Diameter:4 mm Cable Material:TPU Jacket Category:SpO2 Certifications:CE, ISO 13485 Connector Distal:Male 9-Pin D-Sub Purple Connector, Dual Keyed Connector Proximal: Pediatric Finger Clip Latex-free:Yes Packaging Type:PE Bag Packaging Unit:1pcs SpO2 Technology: Nellcor Sterile:No Total Cable Length: 1 meter / 3.28ft Warranty: 12 months Weight:0.3lb Product Feature: 1) LED 660nm / 905nm, the max output power: 2 mw. 2)SpO2 test range：70%~100%；Accuracy：70%~79% /±3%，80%~89% / ±2%，90%~100% / ±1%. 3)Pulse rate test range：30~245 bpm；Accuracy：150 bpm -245 bpm /±3 bpm，60 bpm -149 bpm/±2 bpm，bpm -59 bpm/±1 bpm. 4) Under the environment temperature of 35℃. The maximum allowable temperature of the contact part between a blood oxygen probe and human body shall be no larger than 41℃. 5)Test method for measuring range and measuring precision of SpO2 :Use a supporting device matching the tested spo2 sensor;,connect the tested spo2 sensor and the supporting device, and connect them with a blood oxygen simulation tester.
