ECG Cable Details:
Name: One Piece 10-Lead Banana EKG Cable
Model: AMD-EG-EB7509-I
Compatible brand: SCHILLER–10KΩ
Compatible model: Avionics(DelMar)910/920/930/940/942/950/960/970/980;Custo-med: Custo-norm;Del mar: 910,920,930,940,942,950,960,970,980;Ergoline: Autoruler,Autoscript 6/12,Cardiette, EK 3003/3012,Ergoline;Esaote Biomedica: EKG P120;Fidelity: LP 3000;Innomed: Heart Mirror (3-Kanal);Kontron: EKG P80;Reynolds: Cardiotrack 12;Schiller: AT3,AT5,AT6,AT10,AT60,AT104 PC,AT104,AT101,CS6,CS12,CS100,CS200;Trentina: All Excel-Types;Von Berg:Bioset 9000;Bionet:All models
Plug Style: DB15P
Cable length: 2.4m Cable & (1.2m long leads & 0.8m short Leads)
Cable Color: Gray
Cable Material: TPU
Yoke Style: 10 lead, Bananas
Model No.:
One Piece 10-Lead snap EKG Cable - AMD-EG-ES7509-I
One Piece 10-Lead Clip EKG Cable - AMD-EG-EC7509-I
One Piece 10-Lead Pin EKG Cable - AMD-EG-EI7509-I
One Piece 10-Lead Banana EKG Cable - AMD-EG-EB7509-I
Description:
Be divided into ECG monitor cable, Holter ECG monitor cable, EKG monitor cable, specific specifications reference the label.
Applicable User:
Adult,pediatric,neonate,infant, without limitation for color of skin and gender.
Product performance:
ECG waveform should display clear and complete after the cable and other leadwire component connect to the Parameter patient monitor and ECG machine.
The ECG waveform response time of cable and leadwire components ≤30S.
Main structure:
ECG cable is made up of Equipment connector,trunk cable,Yoke,lead wire and patient terminal.
Intended use:
Compatible with parameter patient monitor and ECG machine to collect and transmit the patient’s ECG activity signal.
