Catheter guidewire PTC-S-C-F5-035-150

ureteral

Global provider of medical devices, plastics solutions and pharmaceutical systems Accoat Standard Guide Wire – Lunderquist PTC Dimensions Ø 0.025” / 0.64 mm Ø 0.035” / 0.89 mm Length 50 cm 60 cm 70 cm 80 cm 90 cm 100 cm 120 cm 150 cm 260 cm Surface Stainless steel PTFE coated Distal tip form Straight tip J-tip radius: 1,5 – 3 – 6 – 15 mm Distal flexible length 5 cm 7 cm 10 cm 12 cm 15 cm 17 cm 20 cm Description of item code PTC-S/Jr-C-F1-0xx-L (example: PTC-S-C-F5-035-150) S Straight tip PTC The guide wire is named after the Perkutan Transhepatic Cholangiograph procedure Jr J-tip radius J1,5 mm tip J3 mm tip J6 mm tip J15 mm tip C PTFE coated Without C Stainless steel F1 Length of the distal exible tip F5 - 5 cm flexible tip F7 - 7 cm flexible tip F10 - 10 cm flexible tip F12 - 12 cm flexible tip F15 - 15 cm flexible tip F17 - 17 cm flexible tip F20 - 20 cm exible tip 0xx Diameter of the guide wire 025: 0.025” (0.64 mm) 035: 0.035” (0.89 mm) L Length of the guide wire 50 - 260 cm
