Catheter guidewire PTC-SCH-S-F5-40-55-035-100

ureteral

Global provider of medical devices, plastics solutions and pharmaceutical systems Accoat Standard Guide Wire – Schüller PTC Dimensions Ø 0.025” / 0.64 mm Ø 0.035” / 0.89 mm Length 50 cm 60 cm 70 cm 80 cm 90 cm 100 cm 110 cm 120 cm 150 cm 260 cm Surface Stainless steel PTFE coated Distal tip form Straight tip J-tip radius: 1,5 – 3 – 6 – 15 mm Distal flexible length 5 cm 7 cm 10 cm 12 cm 15 cm 17 cm 20 cm Proximal flexible length 30 cm 33 cm 35 cm 38 cm 40 cm 43 cm 45 cm 50 cm 53 cm 55 cm 60 cm 63 cm 65 cm PTC The guide wire is named after the Perkutan Transhepatic Cholangiograph procedure SCH Schüller type S Straight tip Jr J-tip radius J1,5 mm tip J3 mm tip J6 mm tip J15 mm tip C PTFE coated Without C Stainless stee F1 Length of the distal exible tip x = cm ex. F5 = 5 cm Available in 5, 7, 10, 12, 15, 17 or 20 cm L1 Length of the stiff cannula part L2 Length of the stiff proximal coil end Available in 30, 33, 35, 38, 40, 43, 45, 50, 53, 55, 60, 63 or 65 cm 0xx Diameter of the guide wire 025: 0.025” (0.64 mm) 035: 0.035” (0.89 mm) L Length of the guide wire (Sum of F1+L1+L2)
