Material - SS304
Brand - SPAN
Shape - Rectangular
Design - Customized
Size : Length x Breadth x Height 5’ x 3’ x 3’.
Material : Stainless steel sheet. Grade 304. thickness 1.5mm.
Provided with sink on one side (Left side) of size Length x Breadth x Depth 1.5’ x 1.5’ x 1’ with an outlet pipe of 1.5” and the Outlet top covered with a sieve.
Provided with a tap and an eye wash sprinkler near the sink for connection with a water pipe line.
Top surface should have a right side slope with 2” diameter opening on the right side end centre connected with an outlet pipe of 2” and the outlet top covered with a sieve.
Entire top right side surface covered additionally with a heavy stainless steel perforated 91 cm perforations with 1” between perforations) plates except the sink area on the left side.
All the four sides elevated to a height of 2” to 3”.
All the four legs and frame made of heavy stainless steel pipe of 2” diameter or 2 x 2” square pipe.
All the four legs should be connected at the top below the surface sheet as well as 6” above the ground level by heavy stainless steel pipe of 2” diameter or 2 x 2” square pipe.
Provided on all four sides with a 4” x 2” PU wheel with stopper
