Zero air generator ZA TOTAL

compressed airCO2humidity

Zero air generators completely remove hydrocarbons, CO2, NOx and H20 from the air stream. This avoids the need to use inconvenient air cylinders, which are hazardous for laboratory operations. The AirGen series ZA-HC is able to remove the total hydrocarbons to less than 0.05 ppm from the external compressed Air. If higher purity is requested, then the ZA-Total will also remove other pollutent like Humidity, CO2, CO, NOx , SO2 and Hydrocarbons. Very small in size, the ZA-HC and ZA-Total can filter up to 15 l/min of compressed Air and can withstand a pressure up to 7 bar (101 psi). The reduction of hydrocarbons, including methane, and carbon monoxide decrease the background noise level and gives much better baseline stability, considerably increasing detector sensitivity and ensuring precise analytical results. The hydrocarbons and CO are removed with a catalytic oven filled with palladium, the Humidity and CO2 is removed with a dual molecular sieve PSA system, NO is removed with Purafil and other components are removed with with an active charcoal filter. • GC-FID • GC-NPD • GC-FPD • GC-PFPD • THA • Gas sensing • Easy use and quick installation • High flow rate up to 15 l/min • Pressure up to 7 bar • RS 485 as standard • Purity: < 0.05 ppm THC < 0.1 ppm CO NOx SO2 < 5 ppm CO2 • No maintenance • Reduced foot print • Compatible with HG BASIC and HG PRO
