Pressure transmitter 0690

Stainless steel housing 1.4404 / AISI 316L, hex 22 Pressure transmitters specially for low pressures, including vacuum applications Long life time even under high pressure change rates Housing and wetted parts are made of stainless steel 1.4404 providing excellent media compatibility when used in seawater, chemical and process technology applications The highly-sensitive piezo-resistive sensor in the measuring cell filled with oil guarantees high level of accuracy, repeatability and long-term stability The availability of different sealing materials enables deployment in a broad temperature range and with a diverse array of media Pressure transmitter 0690 - 4 - 20 mA (2-Leiter) Connection: G1/4 - DIN 3852-E Response time: < 2 ms Burst pressure: 40 bar 100 bar 250 bar 35 bar 30 bar 20 bar 10 bar to: 4 - 20 mA Sealing material: NBR FKM Pressure type: Vacuum Overpressure Pressure range from: 10 - 32 VDC Housing material: stainless steel 1.4404 / AISI 316L
