Water bath cooling module RU-500

the cooling head of the Techne® Dip Cooler fits neatly and unobtrusively into the corner of the bath and can be secured with a specially designed mounting bracket (supplied). If cooling can be achieved by using cold tap water, a dip cooler is recommended as it conserves water and is easier and more convenient to use. Techne® Dip Coolers are designed for use when temperatures down to -35°C are required. • Two models • Compact refrigeration units for achieving temperatures down to -35°C (using Techne low-temp oil) • Cooling head of the Dip Cooler fits neatly into the corner of a Techne liquid bath (RU series of Dip Coolers) • Designed for use with Techne liquid baths Technical Specification Cooling (at 20°C ambient) - RU-200 - RU-500 Minimum achievable temperature - –20°C - –35°C Cooling capacity: 20°C - 145W - 240W Cooling capacity: 0°C - 145W - 240W Cooling capacity: –10°C - 110W - 230W Nominal dimensions width (mm) - 235 - 370 Nominal dimensions length - 420 - 430 Nominal dimensions height (mm) - 300 - 325 Coil dimensions (mm) length (mm) - 85 - 85 Coil dimensions (mm) diameter (mm) - 75 - 75 Hose length to coil (mm) - 1250 - 1250
