Artificial ventilation air compressor

1-workstation

The Neumovent Air Compressor provides clean and dry compressed air for medical ventilators. Small, Compact & Advanced design Medical Air compressor The Neumovent Air Compressor provides clean and dry compressed air for medical ventilators. It can be used as a primary source of air or as an automatic backup system, in case of a failure of the main source of air in the medical facility. The Neumovent Air Compressor is available for use with all Neumovent Ventilators: Advance, Neo and Ts. Also, it’s available the Compressor Trolley making a fully integrated system. Technical specification Nominal voltage and frequency (*) 230 V/50Hz - 115 V/60 Hz Compressor efficiency 50 l.min–1/ 3,5bar Peak flow 200 l.min–1 Air tank capacity 2 lit Filtration of air to 5 μm Dew point depression at 3 bar, 20°C 5°C under the ambient temperature Dew point depression at 3 bar, 20°C, with membrane dryer. 10°C under the ambient temperature Outlet connection DISS 1160-A (3/4“-16 UNF) Operation mode Continuous - S1 Wall connection yes Classification according to MDD93/42/EEC,2007/47/EC class II.b Noise level ≤ 50 dB [A] Dimensions(wxdxh)(**) 445x355x440mm Weight (**) 34 kg *Please state voltage and frequency in the order. ** Without trolley
