Gas valve 2-Way

medicalsolenoidstainless steel

OPERATION 2-Way Normally Closed ---> Open when energized. CONNECTION Connection Female 3/8" NPT (ANSI B2.1) - Inlet. Connection Female 3/8" NPT (ANSI B2.1) - Outlet. ORIFICE Ø 16,0 mm - (Kv 4,65) Flow Factor. MATERIAL Body - Brass (ASTM B16). Plunger/Pole - Stainless Steel (AISI 430 Fr). Spring - Stainless Steel (AISI 302). Wire - Enameled Copper Class HR 200°C (IEC 60317-8). SEAL Seal - Fluorcarbon Elastomer (Viton) ELETRICAL PROPERTIES Width 47.5 x Height 42 x Length 59.5 x Diam. 17x34mm Degree of Protection: IP65 Package: Polyamide 6 (30% fiber) 220/240 V 50/60 Hz 14 W DIN 43650A Electric connection MAIN APPLICATIONS Fluid of silica, air, lubricant to the base of Di-Ester, liquid petroleum gas(LGP), H2O, Ethanol, natural gas and cold oxygen gas. * Other applications consult compatibility PRESSURE (PSI) Min. 0 / Max. 150 SPECIAL FEATURES WEIGHT (KG) 0,74400
