Decontamination pass-through WIBOclean

for clean rooms

The WIBOclean active airlocks are used to transfer products and containers into and out of the cleanroom area with a minimum of contamination. The optimal combination of small air nozzles with a high pressure ratio ensures highly effective and efficient surface cleaning. The fully adjustable cleaning cycle is carried out by high-performance fans with up to 450-fold air exchange. During the subsequent recovery process, the airlock is cleaned of particles. The active airlock can be used for cleaning and as a walk-through airlock between the cleanroom and gray room. Standard operation takes place in negative pressure, so that no air flows from the inside to the outside when opening. Program sequence, fault monitoring and locking are regulated by the integrated control system. It can be operated either via push-button or display. Emergency open buttons stop the program and unlock the doors.   The WIBOclean active airlocks can be equipped with roller shutters, lift gates or door elements with viewing windows to the grey and clean room. Ionization units and UVC irradiation units can also be integrated to disinfect the surfaces. A connection for H2O2 decontamination or integrated H2O2 fogging are possible. Can be integrated into existing cleanroom designs Customized solution GMP/FDA-compliant design Cleanliness class 5 according to DIN EN ISO 14644-1 Freely adjustable cleaning cycles and airlock functions Connections for H2O2 decontamination and integrated H2O2 fogging possible Also available as an explosion-proof version
