Clean room air handling unit Slimair 0303

Sizes: 6 Airflow range : from 500 m³/h (1.5 m/s) to 6000 m³/h (3,1 m/s on coil). Self-supporting construction with double skin panels 25 mm thick. Various arrangements possible: single flow in line, double flow in line, side by side, superposed, vertical, and outdoor installation. EN 1886 classification T3 - TB3 - L1 - F9 - D1 (tested by independent TUV laboratory). With 6 models, from 500 to 6000 m³/h. Air handling unit really compact and ultra adaptable designed to cover all market needs with various arrangements possible. Many functions available: Plate heat exchanger, high efficiency motors (IE2 or EC), electrical coils , heating water coils, cooling water coils, direct expansion coils, large choice of filter from G4 to F9, dampers and mixing section 2 or 3 ways, sound attenuators, plates heat exchangers, by-pass, 2-ways mixing section on supply and empty sections. Accessibility by the side with large hinged doors or by the bottom with trapdoors on chassis. Many accessories and options available.
