Medical gas pressure regulator 684NG

laboratorymedical

compact design (e.g. suitable for cylinder cabinets) minimises the risk of accidents and increases the work space ensures continuous gas supply and control of a pipeline completely mounted and tested option: with cut-off valve valve HDS17 conforms to DIN EN ISO 14114 and acetylene regulations (TRAC) Benefits: pressure regulating station completely mounted and tested quick and easy wall mounting compact design (e.g. suitable for cylinder cabinets) pressure regulating station according to DIN EN ISO 14114 pressure regulator according to DIN EN ISO 7291 Operation / Usage: The pressure regulating station ensures continuous gas supply and control of a pipeline, which is connected with pipeline outlets and reduces the risk of accidents A supply by single cylinders is not available Assembly: (1x1) pressure regulating station 684NG (2x1) pressure regulating station 684NG manually changeable consisting of: 2/2-way-high pressure ball valve DN6 1x or 2x dependant on option 1x pressure regulator with blow off valve 1x safety device 85-10 according to DIN EN ISO 5175 against back flow and flashback 1x ball valve in the outlet DN8; G 3/8 F completely mounted and tested on stainless steel plate Options: automatic quick acting shut-off device HDS17 according to EN ISO 15615 flexible hose standards (BAM certified) for connection of pressure regulating station with gas supply (cylinder, gas cylinder manifolds, bundles, ...), adapter suitable for bundle connection
