Pump Size : 15cm(L) X 25cm(W) X 40cm(H)
Mattress Size : 200cm(L) X 90cm(W) X 13cm(H)
Weight : Pump 5kg, Mattress 6kg
Rated Voltage : 220V, 60Hz
Power Consumption : 30VA
Circulation Interval : 3min, 5min, 15min, 20min, static
Feature : CPR facility, Water-proof Cover, Laser Vented Holes
Material : Fabric, PVC
Patient’s Weight : 20~140kg
Air Capacity : 2~7L
Max. Input : 130mmHg
Carton Size : 47 X 42 X 38 (with the mattress)
Quantity in a Carton : 1EA
Decubitus Level : ★★★★
- Pressure control according to a patient’s weight
- Digital control panel
- Cycle time select function
- Air pressure emergency alarm buzzer
- Triple air line circulation
- Soft function (The air pressure maintains 30mmHg)
A fabric is coated on the PVC, so it provides cool feeling during summer and
warm feeling during winter. It’s cell type structureprovides economical benefit,
and this is very efficient to a patientunder long-term treatment. It is a very
practical system with3 cells fixed at the head area, which is used as a pillow.
