Pump Size : 15cm(L) X 25cm(W) X 40cm(H)
Mattress Size : 230cm(L) X 86cm(W) X 10cm(H)
Weight : Pump 5kg, Mattress 10kg
Rated Voltage : 220V, 60Hz
Power Consumption : 30VA
Circulation Interval : 3min, 5min, 15min, 20min, static
Feature : Air pressure emergency function, CPR facility,
Water-proof Cover, Laser Vented Holes
Material : Non-toxic TPU + Fabric
Patient’s Weight : 20~140kg
Air Capacity : 2~7L
Max. Input : 130mmHg
Carton Size : 47 X 42 X 38 (with the mattress)
Quantity in a Carton : 1EA
Decubitus Level : ★★★★
- Pressure control according to a patient’s weight
- Digital control panel
- Cycle time select function
- Air pressure emergency alarm buzzer
- Triple air line circulation
- Soft function (The air pressure maintains 30mmHg)
An Aroma scent is added to non-toxic TPU to benefit a patient’s mental health.
The tubes uniformly support a patient’s body. If there is a damaged tube,
it can be replaced without affectingother tubes, so it is economical.
Especially, this is very efficient to a patient under long-term treatment.
In addition, 3 cells at the head area are fixed for a patient with problem or
a critical patient to provide them more comfort.
