-Provide audible and visual alarms for heart rate violations, VF and VT.
-Provide a strip printer which annotates waveforms, events, time code
-Have a 5-lead patient cable as an option to a 3-lead cable.
-Supplied with external re-usable paddles and pa
Physical characteristics:
Main unit: Portable
Dimensions:L320xW205xH410
Weight:9.5kg
Technical specifications
DEFIBRILLATOR
(1)Defibrillator type: Manual, Synchronized, Asynchronized,
(2)Out put waveform: Biphasic technology
(3)Energy accuracy: ∠+1%
(4)Energy selection: 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joule (nominal ata resistance of 50)
(5)Charging time
Maximum 8 seconds to 360 Joules
(6)Standard Adult/Pediatric Paddles Reusable external adult paddles (pediatric paddles integrated)
Display
-LED Dimensions
7’diagonal {155mm*88mm} which is easily read from a distance.
-Type
High resolution true-color graphic LED
-Resolution
480X234
- Provide cardioversion facilities with waveform annotated on the screen
- Display 4 seconds of ECG at 25mm/sec, ECG selectable from leads I, II, III when used with a 3-lead cable, and I, II, III aVL, aVR, aVF and V when used with a 5-lead cable.
- Display prompts, waveform settings, battery status, event summary and fault codes. Energy select is displayed by push button under the screen.
ECG
ECG lead: Ⅰ, Ⅱ, Ⅲ, AVR, AVL, AVF, V1~V6, GND
S-T segment analysis: -2.0~2.0mv
Arrhythmia analysis: yes
Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation
